Clymer Yamaha Personal Watercraft (1987-1992)
by CWR
Informational Listing
Informational Listing Notice
This product is a sample legacy item from our Loyalty Program Collection, provided in this Product Directory for reference and informational purposes only. It is not currently available in the Loyalty Program for purchase.
This product is a sample legacy item from our Loyalty Program Collection, provided in this Product Directory for reference and informational purposes only. It is not currently available in the Loyalty Program for purchase.
Looking to buy this product?
View this item on AmazonWe may earn a commission if you purchase through this link.
People Also Liked
Clymer Yamaha Personal Watercraft (1987-1992) is a winterizing by CWR. See more in Products C.
Description:
Yamaha Jet Ski and Water Vehicles, 1987-1992
Part #: W805
400 pages
CHAPTER ONE/GENERAL INFORMATION
CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Break-in procedure / 10-hour inspection / Lubrication / Lubrication system identification / Recommended fuel mixture / Fuel mixing / Oil injection service / Oil pump bleeding / Oil filter / Oil tank drain hose / Check valve / Oil tank / 50 and 100 hour maintenance schedule / Fuel filter / Water separator / Fuel filler cap / Fuel tank pickup / Cooling system flushing / Engine tune-up / Torque cylinder head bolts / Cylinder compression test / Spark plug / Ignition timing / Carburetor adjustment / Storage / Specifications
CHAPTER FOUR / ENGINE (500 CC)
Engine lubrication / Service precautions / Serial numbers / Servicing engine in hull / Special tools / Engine removal installation / Muffler housing and exhaust guide / Specifications
CHAPTER FIVE / ENGINE (650 CC) Engine lubrication / Service precautions / Serial numbers / Servicing engine in hull / Special tools / Engine removal installation / Muffler housing / Engine top end / Cylinder / Piston, piston pin and piston rings / Crankcase and crankshaft / Specifications
CHAPTER SIX / DRIVE TRAIN
Intermediate shaft and housing / Jet pump / Ride plate adjustment / Specifications
CHAPTER SEVEN / FUEL AND WATER BOX SYSTEMS
Flame arrestor / Intake manifold and reed valve / Type I Type II Carburetor / Type III Carburetor /Fuel tank / Fuel valve / Water box / Specifications
CHAPTER EIGHT / ELECTRICAL SYSTEM
Battery / Charging system / Electric starting system / Flywheel and stator plate / Flywheel, idler gear and stator plate / Electric box / Switches / Fuel sender / Fuse / Wiring diagrams / Specifications
CHAPTER NINE / OIL INJECTION SYSTEM - WRA650 AND WRB650
Oil tank / Sub oil tank / Check valves / Oil tank breather valve / Oil pump / Specifications
CHAPTER TEN / BILGE SYSTEM
CHAPTER ELEVEN / STEERING SYSTEM
Steering assembly / Specifications
INDEX
WIRING DIAGRAMS
Models covered:
1987 1988 1989 1990 1991 1992 YAMAHA SJ650
1987 1988 1989 1990 1991 1992 YAMAHA WJ500
1987 1988 1989 1990 1991 1992 YAMAHA WR500
1987 1988 1989 1990 1991 1992 YAMAHA WR650
1987 1988 1989 1990 1991 1992 YAMAHA WRA650
1987 1988 1989 1990 1991 1992 YAMAHA WRB650
Product : CLYMER YAMAHA PERSONAL WATERCRAFT 1987-1992
Manufacturer : CLYMER
Manufacturer Part No : W805
UPC : 024185759416
Yamaha Jet Ski and Water Vehicles, 1987-1992
Part #: W805
400 pages
