Clymer Volvo Penta Stern Drives (2001-2004)
by CWR
Informational Listing
Informational Listing Notice
This product is a sample legacy item from our Loyalty Program Collection, provided in this Product Directory for reference and informational purposes only. It is not currently available in the Loyalty Program for purchase.
This product is a sample legacy item from our Loyalty Program Collection, provided in this Product Directory for reference and informational purposes only. It is not currently available in the Loyalty Program for purchase.
Looking to buy this product?
View this item on AmazonWe may earn a commission if you purchase through this link.
People Also Liked
Clymer Volvo Penta Stern Drives (2001-2004) is a winterizing by CWR. See more in Products C.
Description:
Volvo Penta Stern Drives, 2001-2004
Part #: B775
688 pages
QUICK REFERENCE DATA
CHAPTER ONE / GENERAL INFORMATION
CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
CHAPTER FOUR / LAY-UP, WINTERIZING AND FITTING OUT
CHAPTER FIVE / ADJUSTMENTS
Carburetor / Ignition timing / Shift cable and linkage / Throttle cable / Trim position sender and trim limit control module / Specifications
CHAPTER SIX / ENGINE
Removal installation / Engine alignment / Rocker arm cover / Valve adjustment / Placing the No. 1 piston at TDC / Lifter cover / Camshaft lobe lift measurement / Cylinder head / Rocker arm and pushrod / Flywheel housing / Drive coupler / Drive plate / Flywheel / Flywheel pilot bearing / Output drive shaft, seals and bearings / Oil pan pump / Harmonic balancer / Timing gear/chain cover / Timing chain and sprockets / Balance shaft / Camshaft and lifters / Piston and connecting rod / Rear main seal and rear main seal carrier / Crankshaft / Break-in procedure / Specifications
CHAPTER SEVEN / FUEL SYSTEMS
Fuel system service / Mechanical fuel pump / Low-pressure electric fuel pump / Carburetor / Electronic fuel injection (EFI) / Intake manifold / Specifications
CHAPTER EIGHT / COOLING AND EXHAUST SYSTEMS
Thermostat / Recirculation pump / Seawater pump / Oil and power steering fluid cooler / Exhaust elbow / Exhaust bellow and flapper valve / Exhaust tube and flapper valve / Exhaust manifold / Specifications
CHAPTER NINE / ELECTRICAL SYSTEM
Battery / Alternator / Starter motor and solenoid / Starter relay / Fuel pump relay / EFI system relay / Ignition system / Oil pressure sender / Oil pressure switch / Engine temperature sender / Engine temperature sensor / Engine overheat switch / Exhaust overheat switch / Intake air temperature sensor IAT / Throttle position sensor TPS / Idle air control motor IAC / Knock sensor / Knock sensor module / Engine control unit ECU / Warning horn replacement / Specifications
CHAPTER TEN / DRIVE UNIT
Drive unit service precautions / Drive unit identification / Drive unit operation / Drive unit gear ratio / High altitude operation / Outdrive service precautions / Sacrificial anodes / Shifting and propeller rotation / Propeller / Drive unit removal and installation / Upper drive shaft housing / Universal joint / Shift housing service / Pressure and vacuum test / Specifications
CHAPTER ELEVEN / INTERMEDIATE HOUSING AND TRANSOM SHIELD/BRACKET
Intermediate housing operation and inspection / Intermediate housing and suspension fork / Transom shield and mounting collar / Transom bracket / Specifications
CHAPTER TWELVE / POWER TRIM SYSTEM
Trim relay / Trim switch fuse / Trim limit control module / Trim motor / Trim pump / Fluid reservoir / Fluid screen / Hydraulic pump / Relief valve / Trim cylinder / Trim hose / Trim position sender / Filling and bleeding the trim system / Specifications
CHAPTER THIRTEEN / STEERING SYSTEM
Safety precautions / Mechanical (manual) steering system / Power steering system / Specifications
