Clymer MerCruiser Stern Drives 1964-1985 w-TR & TRS, (1986-1987)
by CWR
Informational Listing
Informational Listing Notice
This product is a sample legacy item from our Loyalty Program Collection, provided in this Product Directory for reference and informational purposes only. It is not currently available in the Loyalty Program for purchase.
This product is a sample legacy item from our Loyalty Program Collection, provided in this Product Directory for reference and informational purposes only. It is not currently available in the Loyalty Program for purchase.
Looking to buy this product?
View this item on AmazonWe may earn a commission if you purchase through this link.
People Also Liked
Clymer MerCruiser Stern Drives 1964-1985 w-TR & TRS, (1986-1987) is a winterizing by CWR. See more in Products C.
Description:
MerCruiser Stern Drives, 1964-1985 with TR and TRS, 1986-1987
Part #: B740
616 pages
CHAPTER ONE / GENERAL INFORMATION
CHAPTER TWO / TOOLS AND TECHNIQUES
CHAPTER THREE / TROUBLESHOOTING
CHAPTER FOUR / LUBRICATION, MAINTENANCE AND TUNE-UP
CHAPTER FIVE / LAY-UP, COOLING SYSTEM AND FITTING OUT
CHAPTER SIX / GM INLINE ENGINE
Removal installation / Rocker arm cover / Intake exhaust manifold / Crankshaft pulley torsional damper / Timing gear cover and seal / Rocker arm / Camshaft / Oil pan / Oil pump / Cylinder head / Valves and seats / Piston connecting rod / Crankshaft / Flywheel / Cylinder block / Core plug / Specifications
CHAPTER SEVEN / GM V6 AND V8 ENGINES
Removal installation / Rocker arm cover / Intake exhaust manifold / Crankshaft pulley and torsional damper / Front cover and seal / Timing chain and sprockets / Rocker arm / Camshaft / Oil pan / Oil pump / Cylinder head / Valves and seats / Piston connecting rod / Crankshaft / Rear main oil seal / Flywheel / Cylinder block / Core plugs / Specifications
CHAPTER EIGHT / FORD V8 ENGINES
Removal installation / Disassembly checklists / Rocker arm cover / Intake manifold / Exhaust manifolds / Crankshaft pulley and vibration damper / Front cover and seal / Timing chain and sprocket / Rocker arm / Camshaft / Oil pan / Oil pump / Cylinder head / Valves and seats / Piston connecting rod / Crankshaft / Rear main bearing oil seal / Flywheel / Cylinder block / Core plugs / Specifications
CHAPTER NINE / MERCRUISER 60, 80 AND 90 ENGINES
Removal installation / Rocker arm cover / Intake exhaust manifolds / Inner transom plate / Front cover and seal / Rocker arm / Camshaft and timing chain / Oil pan pump / Cylinder head / Valves and seats / Piston connecting rod / Crankshaft / Flywheel / Cylinder block / Core plugs / Specifications
CHAPTER TEN / MERCRUISER 470, 485, 488, 170MR AND 190MR
Removal installation / Rocker arm cover / Intake exhaust manifold / Alternator rotor/stator / Front cover and seals / Rocker arm / Camshaft / Timing chain and sprockets / Oil pan / Oil pump / Cylinder head / Valves and seats / Piston connecting rod assembly / Crankshaft / Flywheel / Cylinder block / Core plugs / Specifications
CHAPTER ELEVEN / FUEL SYSTEM
Carburetors / Fuel pump / Specifications
CHAPTER TWELVE / COOLING SYSTEM
Thermostat / Engine circulating pump / Seawater pickup pump / Seawater engine pump / Specifications
CHAPTER THIRTEEN / ELECTRICAL SYSTEMS
Direct drive alternator charging system / MerCrusier 470 alternator charging system (air-cooled regulator) / MerCrusier 470, 485 and 488 (water-cooled regulator) / Delco-Remy external regulator system / Motorola alternator system / Mando alternator system /Drive belt adjustment replacement / Starting system / Ignition system / Breaker point distributor / Thunderbolt distributor / Ignition coil / Ignition resistance wire / 2-station tachometer switch / Switch panel test / Power trim control panel switch / Power trim indicator sender / Neutral safety switch / Specifications
CHAPTER FOURTEEN / MERCRUISER DRIVE SYSTEM
MerCruiser Model O / MerCruiser Model I / MerCrusier Model II non-transom mounted / MerCruiser Model II transom-mounted models / MerCruiser II-TR, II-TRS and 215-H / MerCruiser 215-E / Specifications
CHAPTER FIFTEEN / GEAR HOUSING
Model I drive / Model II drive / Model II-TR and II-TRS gear housing / Model I-MR drive / Specifications
CHAPTER SIXTEEN / DRIVE SHAFT HOUSING
Model I drive / Model II / Model II-TR and II-TRS drive / Specifications
CHAPTER SEVENTEEN / BELL HOUSING, GIMBAL BEARING AND GIMBAL RING
I-drive bell housing / II-TRS bell housing / Gimbal bearing / Gimbal ring / Specifications
CHAPTER EIGHTEEN / POWER TRIM AND TILT SYSTEMS
INDEX
WIRING DIAGRAMS
Models covered:
1986 1987 MERCRUISER MODEL 0
1986 1987 MERCRUISER MODEL 215
1986 1987 MERCRUISER MODEL I
1986 1987 MERCRUISER MODEL II
1986 1987 MERCRUISER MODEL II-TR
1986 1987 MERCRUISER MODEL II-TRS MERCRUISER MODEL III
Product : CLYMER MERCRUISER STERN DRIVE 1964-1985
Manufacturer : CLYMER
Manufacturer Part No : B740
UPC : 024185761310
MerCruiser Stern Drives, 1964-1985 with TR and TRS, 1986-1987
Part #: B740
616 pages
